| Business Type | Manufacturer, Exporter, Supplier |
| Type | Drill Machine |
| Drilling Diameter | 25 - 60 Mm |
| Item Weight | 200 Kg |
| Click to view more | |
Product Details
Variable Speed
Variable Speed
Warranty
1 Year
Automatic Grade
Semi-Automatic
Overall Height
2250 Mm
Power Consumption
3728 W
Brand Name
Accumax
We have gained expertise in manufacturing a wide range of Heavy Duty Radial Drilling Machines etc. These machines are widely used to deliver stable performance during drilling process. In addition to this, the machines offered by us provide flawless operations for longer hours due to the drilling heads with longest possible radius from the columns. Our range of machines are used in woodworking, metalworking and construction applications.
Specification
| Size | 25 MM | 40 MM | 50 MM |
| Drilling capacity | 25 MM | 40 MM | 50 MM |
| Pillar Diameter | 130 MM | 170 MM | 250 MM |
| Spindle nose to table distance | 675 MM | 705 MM | 1000 MM |
| Distance from spindle nose to base distance | 875 MM | 995 MM | 1200 MM |
| Distance from spindle center to pillar surface | 635 MM (Max) | 790 MM (Max) | 900 MM |
| Taper in spindle | MT – 3 | MT – 4 | MT – 4 |
| Number of speed | 8 Speed | 8 Speed | 8 Speed |
| Range of Speed (RPM) | 130 to 2600 | 70 to 2000 | 40 to 615 |
| Table Size (in mm) | 200 x 200 x 255 | 290 x 290 x 375 | 420x390x280 |
| Base size (Machined Area mm) | 585 x 915 MM | 735 x 1240 MM | 1500 x 800 MM |
| Overall Base Size (in mm) | 610 x 940 MM | 745 x 1260 MM | 1500 x 800 |
| Spindle Travel | 185 MM | 215 MM | 220 MM |
| Pillar Length | 1265 MM | 1490 MM | 1200 MM |
| Overall height with pulley guard | 1700 MM | 1960 MM | 2400 MM |
| V-Belt section | B – 43″ & A – 23″ | B – 45″ & A – 24″ | B – 47″ & A-25 |
| Weight (Approx.) | 475 KGS. | 800 KGS. | 1000 KG |
| Motor1440 RPM 3 Phase440 volts | 1 HP & 0.5 HP | 1.5 HP & 0.5 HP | 2 HP & 1 HP |
